UART: Single Msg Transmit Polling

The next example just configure the USART in UART mode with 9600 bauds, 8 bits, no parity 1 bit stop. The program only send a short message every one second in polling mode, what means the HAL_UART_Transmit will only returns after the message is completely send, or after 5 seconds if the message could not be send

#include "bsp.h"

UART_HandleTypeDef UartHandle; /*uart handler structure*/

int main(void)
{
    HAL_Init(); /*init cube library*/

    /*uart configuration options for module USART2, 9600 baudrate,
    8bits, 1 stop bit, no parity, no flow control, and 8 bit lenght */
    UartHandle.Instance         = USART2;
    UartHandle.Init.BaudRate    = 9600;
    UartHandle.Init.WordLength  = UART_WORDLENGTH_8B;
    UartHandle.Init.StopBits    = UART_STOPBITS_1;
    UartHandle.Init.Parity      = UART_PARITY_NONE;
    UartHandle.Init.HwFlowCtl   = UART_HWCONTROL_NONE;
    UartHandle.Init.Mode        = UART_MODE_TX_RX;
    UartHandle.Init.OverSampling = UART_OVERSAMPLING_16;
    /*init uart2 with previous paramters*/
    HAL_UART_Init( &UartHandle );

    while (1)
    {
        /*Transmit a string of characters every second with a timeout of 5 seconds.
        since Tx is made using polling the last paramter indicates the max time to wait
        in case peripheral never sends the data*/
        HAL_UART_Transmit( &UartHandle, "Hello\r\n", sizeof("Hello\r\n"), 5000 );
        HAL_Delay( 1000 );
    }
}

msps.c

/*The function is called from HAL_UART_Init at the very beginning
and allows us to set the pins to be used as serial port*/
void HAL_UART_MspInit( UART_HandleTypeDef *huart )
{
    GPIO_InitTypeDef GPIO_InitStruct; /*gpios init structure*/

    __HAL_RCC_USART2_CLK_ENABLE();    /*enable usart2 clock*/
    __HAL_RCC_GPIOA_CLK_ENABLE();     /*eneable port A clock */

    /*set pin 2(tx) and pin 3(rx) from port A in altern mode usart2
    the altern mode info can be found in device datasheet*/
    GPIO_InitStruct.Pin   = GPIO_PIN_2 | GPIO_PIN_3;
    GPIO_InitStruct.Mode  = GPIO_MODE_AF_PP;
    GPIO_InitStruct.Pull  = GPIO_NOPULL;
    GPIO_InitStruct.Speed = GPIO_SPEED_FREQ_HIGH;
    GPIO_InitStruct.Alternate = GPIO_AF1_USART2;
    /*apply configuration configuracion*/
    HAL_GPIO_Init( GPIOA, &GPIO_InitStruct );
}
